Teltonika TRB145 LTE RS485 Gateway

Product description

Industrial GSM/GPRS Gateway Board TRB145 is equipped with an RS485 Interface, Digital Inputs/Outputs and a microUSB port.

TRB145 compact design makes this Gateway perfect for an application where a sole gadget must be remotely controlled over RS485 interface.

The gateway is engineered to be used in Industrial applications, therefore, it has a wide range of software features

such as SMS control, Firewall, OpenVPN, IPsec, RMS and FOTA support.

Package contents

• Device
• LTE antenna with cable
• Power adapter (EU)
• USB cable



  Technical parameters

  Connectors and Interfaces

  RF connectors : (1) SMA female

  Serial port : RS-485

  SIM slot : Yes

  SIM slots quantity : 1

  USB : Yes

  Power

  Power type : DC connector

  Max. power consumption [W] : 5

  Power via connector/terminal : 9 .. 30V DC

  Physical characteristics

  Buttons : Reset

  Operating temperature [°C] : -40 up to 75

  Weight [g] : 150

  Width [mm] : 60

  Height [mm] : 18

  Depth [mm] : 70

  Hardware

  CPU : ARM Cortex A7

  CPU frequency [MHz] : 1200

  Internal storage [MB] : 512

  RAM [MB] : 128

  Software

  Operating system : RutOS (OpenWrt based Linux OS)
